Qauv Yas Txhaj Moulding

Cov yam ntxwv ntawm txhuas tuaj pwm:
Lub teeb yuag
 Qhov qis dua ntawm aluminium alloy ua cov pwm sib zog thiab ua kom yooj yim txheej txheem, thauj, thiab sib sau ua ke.
 Nws txo qhov xav tau kev txhaj tshuaj molding tshuab tonnage thiab lowers tus nqi ntawm kev siv cov khoom ua khoom siv ua.
Siab siab thermal conductivity
 Txhuas alloys muaj cov thermal zoo heev, uas muaj ntau lub sijhawm txias thiab txhim kho kev txhaj tshuaj moulding khoom.
 Qhov no yog tshwj xeeb tshaj plaws rau sai molding thiab luv - kev ntau lawm.
Yooj yim tshuab
 Aluminium yog cov khoom siv softer, ua kom yooj yim rau CNC machining, txiav, txav, thiab lwm yam haujlwm.
 Lub voj voog ntau lawm yog luv luv, feem ntau tsuas yog 3-10 hnub los ua kom tiav cov pwm.
Nqi txiaj ntsig
 Cov nqi ntau lawm yog qis dua li cov hlau pwm, ua rau nws haum me me - batch profuct cov haujlwm nrog cov nyiaj siv tsawg.
 Cov txheej txheem kev kho cua sov thiab cov txheej txheem tawv me me tsis tas yuav muaj, ntxiv txo tus nqi tsim khoom.
Zoo saum npoo ua tiav
 Qhov saum npoo ntawm txhuas yog ib qho yooj yim los ua polished, sandblasted, anodized, thiab lwm yam, uas tuaj yeem sib haum xeeb.

Qhov zoo ntawm txhuas tuaj pwm:
Luv luv Ntau Lawm
 Los ntawm kev tsim qauv rau kev xa khoom, txhuas pwm feem ntau tsuas yog 3 hnub rau 2 lub lis piam, uas tau nrawm dua li cov khoom ntim cov hlau tuaj pwm.
Pheej yig
 Haum rau me me batch lossis ad - hoc Production xav tau, nws tuaj yeem txo cov nqi kev txhim kho thawj zaug.
Tsis tawv
 Lub pwm qauv tuaj yeem hloov tau yooj yim, uas yog tsim nyog rau cov txheej txheem kev txhim kho cov khoom kom sai.
Haum rau ntau yam khoom
 Cov duab nyuaj lossis nyias {-}}}}}}}}}}}}}}}} cov khoom tsim kom tau raws li cov khoom tsim kho cov khoom sib txawv.
Yooj yim txij nkawm
 Aluminium pwm nto kev kho yog yooj yim, nrog tus nqi txij nkawm tsawg.

Qhov tsis zoo ntawm txhuas pwm:
Luv Lub Neej
 Aluminium alloy muaj tsawg hardness thiab absuction kuj. Feem ntau tsuas tuaj yeem tiv thaiv 500-10,000 kev txhaj tshuaj, uas tsis tuaj yeem ua tiav qhov kev thov ntawm pawg ntau lawm.
Tsis zoo kub tiv
 Txhuas tsis muaj peev xwm tiv thaiv lub peev xwm ntau, thiab lub siab siab - kev txhaj tshuaj kub tej zaum yuav ua rau muaj kev sib xyaw ua yeeb yam.
Tsis muaj zog
 Rau cov khoom lag luam uas xav tau lub zog siab los yog ultra - kev txhaj tshuaj muaj fiber ntau (piv txwv li cov iav fiber ntau ntxiv), tsis haum.
Limited precision
 Txawm hais tias txhuas pwm tuaj yeem ua tiav qhov kev tsim nyog siab dua, lub peev xwm tiv thaiv kev muaj peev xwm tseem me dua me me {{0} {kawg steel pwm.

Scararios rau txhuas cov pwm:
Kev Loj Hlob
 Txheeb xyuas qhov ua tau ntawm kev tsim qauv thiab tsim kho sai sai sai sai rau kev sim.
Cov Pob Me Me Ntau Lawm
 Ua tau raws li cov khoom siv ntau lawm ntawm kaum rau ntau txhiab daim, haum rau kev sib hais cov khoom lag luam thiab kev kuaj ua lag luam theem.
Cov khoom pov thawj
 Tsim cov qauv coj mus rau ntau lawm rau kev ua haujlwm pov thawj lossis tsos pom.
Cov Sij Hawm Luv Luv Luv Luv Luv
 Thov rau cov haujlwm tsim khoom nrog cov sijhawm xa khoom kom muaj txiaj ntsig los txhawb kev tig rov qab sai.

Saj zawg zog Hlau pwm

Cov yam ntxwv ntawm Mos Steel pwm:
Muaj Zog Muaj Zog
 Cov khoom tawv yog feem ntau ntawm 28- 32 HRC, uas tuaj yeem ua tau raws li qhov xav tau ntawm cov khoom txhaj tshuaj nruab nrab (5,000 rau 50,000 mus mais).
 Yooj yim rau kev ua haujlwm nrog ntau dua steel steel pwm, muaj peev xwm tiv taus rau ib theem ntawm lub zog thiab siab.
Zoo dua qub tsis kam
 Cov hlau muag muag tau hnav zoo dua li txhuas pwm, ua rau nws haum rau lub sijhawm ntev dua.
Tus nqi nruab nrab
 Tus nqi qis dua piv rau cov khoom siv pwm tawv, tab sis muaj lub zog ntau dua li txhuas cov dej num nrog cov peev txheej nruab nrab nrog cov peev nyiaj tsawg.
Yooj yim hloov
 Lub siab tawv ntawm cov khoom tso cai rau pwm kom tau yooj yim ua thiab hloov kho tom qab lub mould kev txiav txim, txhawb tsim tsim kev txhim kho.
Versatility
 Yuav siv tau los ua kom cov txheej txheem nyuaj lossis ntau - kab noj hniav pwm kom tau raws li ntau yam cov khoom xav tau.

Cov txiaj ntsig zoo ntawm cov hlau hloov tau pwm:
Lub neej ntev dua
 Feem ntau txhawb txoj kev txhaj tshuaj ntawm ntau txhiab tus txhaj caij tsheb kauj ruam, ua kom haum rau nruab nrab - tsis muaj.
Lub Sijhawm Sib Tw Nruab Nrab
 Kev ua haujlwm nrawm yog nrawm dua li ntawm cov tawv me me pwm. Tab sis me ntsis qeeb dua li cov txhuas pwm, nrog lub voj voog ntau ntau yam li 2-4 lub lis piam.
Nqi -}}}}
 Qhov sib npaug ntawm lub zog, lub neej, thiab tus nqi. Nws yog qhov tshwj xeeb tshaj yog rau kev ua haujlwm kev ua haujlwm, ntau lawm, thiab qee cov phiaj xwm ntau lawm.
Haum rau ntau ntau ntawm cov plastics
 Haum tau kev txhaj tshuaj molding ntawm feem ntau engineering plastics, suav nrog abs, pc, pp, thiab lwm yam.
Siab dua
 Piv nrog txhuas pwm, hloov tau cov pwm hlau hloov tau tuaj yeem ua tiav qhov tseeb ntau dua thiab qhov ua tiav nto.

Qhov tsis zoo ntawm cov mos mos pwm:
Tsawg Hardness
 Weak for ultra-high-pressure force injection molding or processing of glass-fiber-reinforced materials
Tsis zoo corrosion tsis kam
 Nquag mus rau xeb nyob rau hauv high av noo lossis Acidic ib puag ncig, uas xav tau kev tu ib txwm thiab daim ntawv thov ntawm xeb inibitors.
Hnyav
 Hnyav dua li txhuas pwm, ua rau muaj kev thauj mus los thiab cov nqi sib dhos.
Lub sijhawm ua haujlwm ntev tsis zoo li cov hlau pwm
 Tsis tuaj yeem txhawb nqa ntev -} Term Loj Ntau Lawm Xav Tau. Tsis haum rau cov phiaj xwm nrog ntau tshaj ib lab toj mus los.

Cov Khoom Siv Uas Muag Rau Cov Hlau Moulds
P20 Hlau
 Feem ntau siv hardness pwm pwm hlau, Hardness hauv 28-32 HRC, Haum rau hauv nruab nrab lub ntsiab.
 Good workability, moderate wear resistance, cost-effective.
718 steel hlau
 Chromium {{0 {}} muaj pwm hlau muaj cov coj zoo thiab corrosion tsis kam.
 Feem ntau siv nyob rau hauv kev xav tau pwm, xws li pob tshab, thiab qhov chaw ntsuas.
S50c Hlau
 Ib tug carbon Tool steel uas yog pheej yig tab sis tsis tshua muaj zog.
 Haum rau luv - TSHEM Siv Siv lossis Tsawg- Cov Nyiaj Siv Nyiaj.
Nak80 Hlau
 Cov txheej txheem polished yog qhov tsim nyog rau cov khoom uas yuav tsum tau ua kom muaj kev ua tiav siab, xws li cov tsev kom huv si.

Kev sib piv ntawm cov hlau mos pwm nrog lwm cov pwm

3D Luam Ntawv Tuaj Pwm

Nta 3D luam tawm pwm:
Siab yooj yim
 Cov kab ke geometric tuaj yeem luam tawm nrog qib siab ntawm kev tsim kho cov qauv, xws li tsim cov txheej txheem kev coj ua thiab kev tsim lub teeb ci ntsa iab.
Luv luv Ntau Lawm
 Feem ntau, 1-3 hnub kom ua tiav cov pwm tsim, piv nrog cov tshuaj ib txwm pwm kom txuag tau ntau lub sijhawm.
Tus nqi qis
 Tshwj xeeb tshaj yog haum rau me me batches lossis ib {- kev tsim khoom, zam lub siab txhawb nqa cov khoom lag luam.
Cov Khoom Siv Ntau
 YAS, PAMEAMSITURATE Rogram, cov hmoov hlau, thiab lwm yam ntaub ntawv tuaj yeem siv los kho cov kev ua tau zoo ntawm cov pwm raws li qhov kev thov.
Haum rau kev tsim qauv
 Ua pwm pwm tuaj yeem ua tau sai rau cov khoom tsim qauv pov thawj lossis me- NTU NTAU LAWM.

Qhov zoo ntawm 3D luam tawm pwm:
Ceev Sai Me
 Ntawm kev tsim qauv rau molding rau cov sij hawm rau hnub, haum rau kev faib tawm sai dua thiab siv tau.
Tus nqi qis
 Tshem tawm cov kev xav tau rau cov khoom kim me me pwm hlau thiab tshuab ua tshuab, ua rau nws haum rau qis-} tej yaam num.
Cov Qauv Tsim Kev Raug
 Kev siv yooj yim ntawm cov txheej txheem sab hauv, cov chaw ua kom zoo nkauj, thiab kev ua kom ua tau zoo xws li hydrodynamic txias raws.
Txo cov khoom siv pov tseg
 Cov kev tsim teb ntxiv tsuas yog cov ntaub ntawv uas yuav tsum muaj thiab yog ib puag ncig ib puag ncig ntau dua li cov txheej txheem qub tsooses.
Tsim Kev Txhawb Nqa Txhim Kho
 Yooj yooj yim los hloov pwm pwm raws li xav tau thaum lub sijhawm tsim khoom kom hloov kho kom haum rau kev thov.

Qhov tsis zoo ntawm 3D luam tawm pwm:
Luv luv lifespan
 Piv nrog tsoos hlau pwm, 3D {-}} Cov luam tuaj pwm tsis tau siv sijhawm ntev thiab tsis haum rau kev siv lub siab thiab kub.
Tsawg load -} Cov kabmob muaj peev xwm
 Tshwj xeeb cov pwm ua los ntawm cov yas lossis resin yog ib qho yooj yim kom deformed lossis puas nyob rau hauv cov txheej txheem kev txhaj tshuaj lossis tuag {{0} {{0} {{0} {{0} {{0} {0} {{0} {0} {{0} {0} {0} {{0} {{0} {{0} {{0} {0} {{| casting.
Txwv precision thiab qhov chaw zoo
 Qhov kev ntxhib los mos txheej ntawm cov txheej txheem sau ntawv yuav tsum tau ua kev ua ntxiv, thiab cov saum npoo ua tiav tsis zoo li cov ua pwm.
Cov khoom siv cov khoom txwv
 Txawm hais tias hlau 3D tshuab luam ntawv thev naus laus zis, tus nqi yog cov txhab loj, thiab cov pwm ua ke tau txwv hauv lawv qhov kev siv tau.
Tsis txaus batch muaj peev xwm
 Haum rau me me batch kev sib tw ntau lawm lossis siv tau, tab sis tsis haum rau ntev -}} term loj ntau lawm.

Cov Khoom Xaiv Xaiv rau 3D Luam Ntawv Pwm:
Yees duab Resin
 Haum rau me me batch txhaj tshuaj ntsuam xyuas lossis cov ntaub ntawv pov thawj, nrog kev ua kom zoo dua thiab nthuav dav.
Yas (piv txwv li pla, ABS)
 Pwm Luam Tau Siv FDM Technology, tus nqi tsawg, tab sis qis dua kub tsis kam thiab lub zog.
Tej hlau
 Pwm Luam Tau Siv Hlau Hlau (piv txwv li cov hlau stainless, aluminium alloy) yog qhov tsim nyog rau siab lub zog thiab qhov siab xav tau, nrog tus nqi siab dua.
Ntawv Sau Khoom
 Luam ntawv pwm los ntawm kev siv yas lossis cov khoom siv sib xyaw rau cov khoom siv ua kom zoo thiab ua haujlwm.

Kev sib piv ntawm 3D luam tawm pwm thiab pwm pwm:

Silicone Mould

Cov yam ntxwv ntawm silicone pwm:
Siab hloov thiab mallability
 Silicone cov ntaub ntawv muaj kev hloov pauv tau zoo thiab ductility. Thiab tuaj yeem raug cov ntsiab lus ntawm cov npoo ntawm leej niam pwm, haum rau cov duab geometric.
Cov Kub Kub Kuj thiab Tshuaj Muaj Zog
 Siab - Zoo} Zoo Ua Pwm Siab Silicone feem ntau tsis kam mus rau qhov kub (-qib degree) thiab tiv taus ntau yam tshuaj lom neeg.
Tus nqi qis
 Tsawg tus nqi tsim khoom ua rau lawv tsim nyog rau cov me me - kub ntau lawm thiab prototyping.
Luv luv Ntau Lawm
 Cov txheej txheem ntau lawm yog yooj yim, feem ntau 1-3 hnub kom tiav cov pwm ntau lawm thiab muab tso rau hauv kev siv.
Ntau yam ntawm cov ntawv thov
 Yuav siv tau rau molding ntau cov ntaub ntawv, suav nrog resins, polyurethane, siv quav ciab, qis melting point hlau, thiab lwm yam.

Qhov Zoo ntawm Silicone Pwm
Yooj Yim Raug
 Yooj yim tsim cov txheej txheem, tsis xav tau rau cov cuab yeej siv nyuaj lossis cov txheej txheem.
Tsawg -} siv tus nqi yoog
 Qhov zoo tagnrho rau kev siv me me lossis protototyping, nrog cov nyiaj khaws nyiaj tseem ceeb hauv kev tsim kho.
Kev Tshaj Tawm Kev Loj Siab Tiag
 Muaj peev xwm ua kom raug cov ntsiab lus ntawm tus tswv pwm, suav nrog feeb textures thiab cov txheej txheem nyuaj.
Tsis tawv
 Yooj yim tso cov pwm, zam kev puas tsuaj rau cov khoom tiav.
Kev xaiv dav ntawm cov ntaub ntawv
 Yuav siv tau rau molding ntau cov ntaub ntawv xws li cob, polyurethane, gypsum, thiab qis melting point hlau.

Qhov tsis zoo ntawm Silicone Pwm:
Luv Lub Neej
 Piv nrog hlau pwm, silicone pwm muaj cov nqi luv luv thiab lub neej ntev. Thiab feem ntau tsuas tuaj yeem ua ntau yam kaum mus rau ntau pua cov khoom.
Cov Khoom Siv Hluav Taws Xob
 Silicone pwm muaj qis hardness thiab lub zog, ua rau nws nyuaj rau withstand siab {{}- kev txhaj tshuaj molding.
Tsis txaus sab ruaj khov
 Silicone pwm muaj zog rau deformation vim tias tau siv dua, cuam tshuam rau qhov tseeb ntawm cov khoom lag luam.
Nkag siab rau ib puag ncig
 Silicone cov ntaub ntawv muaj kev txhawj xeeb rau cov av noo thiab qhov kub thiab yuav tsum tau khaws cia hauv cov xwm txheej zoo.

Xaiv cov khoom siv Silicone
Pob tshab Silicone
 Rau qhov ntsuas cov pwm thiab pom cov ntawv thov ua kom pom.
Siab Hardness Silicone
 Muab cov txheej txheem zoo dua thiab muaj qhov tsis ruaj khov, thiab tsim nyog rau me me - batch ntau lawm.
Zaub mov qeb silicone
 Siv rau cov zaub mov pwm ua, xws li chocolate thiab ncuav mog qab zib pwm.
Muaj silicone
 Haum rau kev lag luam feem ntau lawm, xws li cov chaw tsheb, ntsaws ruaj ruaj, thiab lwm yam.

Epoxy Resin Pwm

Cov yam ntxwv ntawm Epoxy Resin pwm:
Siab zog thiab hnav tsis kam
 Lub Epoxy Resin hardens los ua ib qho nyuaj saum npoo uas tuaj yeem tiv taus cov txheej txheem ntawm kev ntxhov siab ntawm cov txheej txheem thiab ntev {{} siv sijhawm.
Tshuaj Zoo Kev Tiv Thaiv
 Resistant rau acid, alkali, thiab cov kuab tshuaj uas ntxim nyiam tshaj plaws, tshwj xeeb tsim nyog rau resin impregnation molding ntawm cov khoom siv sib xyaw.
Zoo heev Thermal ruaj khov
 Epoxy Resin pwm tuaj yeem tiv thaiv kom ntau kub (feem ntau 120 degree, tshwj xeeb epoxy tuaj yeem tiv taus nce txog 250 degree), haum rau cov xovxwm xovxwm moulding.
Siab sab downensional qhov tseeb
 Tsawg tus tshuaj shrinkage (feem ntau tsawg dua 1%) tswj cov ncauj lus kom ntxaws thiab cov qauv tseeb ntawm tus tswv pwm.
Siab Nto Acyness
 Qhov saum npoo ntawm cov pwm tuaj yeem ua polished rau daim iav nyhuv, uas pab txhim kho qhov zoo ntawm cov khoom tiav thiab cov nyhuv tso tawm.

Qhov zoo ntawm Epoxy Resin pwm:
Tus nqi raug qis
 Tus nqi qis dua li hlau pwm, haum rau me ntau ntau lawm thiab ua yeeb yam.
Lub teeb yuag
 Piv rau cov pwm pwm, epoxy resin cov pwm muaj qhov sib dua hauv qhov hnyav, ua kom yooj yim rau lis thiab tswj hwm.
Siab corrosion tsis kam
 Tiv taus ntau yam ntawm cov tshuaj lom neeg thiab cov khoom siv, txuas ntxiv lub neej ntawm pwm.
Ua haujlwm siab
 Cov khoom tuaj yeem hloov kho tau nrog cov fillers lossis lwm cov ntaub ntawv txhawb ntxiv kom tau raws li ntau cov txheej txheem xav tau.
Ceev moulding muaj peev xwm
 Cov voj voog luv luv, tsim nyog rau cov lus teb ceev ceev rau kev ua lag luam thov.

Qhov tsis zoo ntawm epoxy cob pwm:
Muaj kev ruaj khov
 Piv nrog hlau pwm, epoxy resin pwm tsis tshua tiv taus kev cuam tshuam thiab kev puas tsuaj. Thiab yog haum rau me me thiab nruab nrab - qhov loj me ntau ntau lawm.
Qis dua thermal conductivity
 Thermal conductivity yog qis dua li hlau pwm, uas yuav txo cov khoom lag luam hauv qee cov txheej txheem cua sov.
Qhov Kev Xav Tau Siab
 Nws yog ib qho yooj yim rau kev puas tsuaj rau saum npoo ntawm cov pwm thaum los daws, yog li nws yog qhov tsim nyog los siv lub siab {{}} Zoo pwm cov neeg sawv cev.
Yooj yim rau deform nyob rau hauv loj loj
 Loj - Qhov loj me pwm tuaj yeem ua rau muaj kev ntxhov siab hauv kev ntxhov siab lossis ib puag ncig kub.

Saib xyuas thiab tu ntawm epoxy cob pwm:
Ntxuav lub nplaim
 Ntxuav saum npoo ntawm pwm tom qab txhua qhov siv kom tsis txhob muaj kev puas tsuaj rau cov pwm.
Kev kuaj xyuas tsis tu ncua
 Tshawb xyuas cov pwm tsis tu ncua rau cov kab nrib pleb, deformation, lossis hnav.
Kev siv cov pwm tawm ntawm cov pwm
 Thov cov neeg sawv cev tso tawm tusyees ua ntej txhua qhov siv los txo kev puas tsuaj rau pwm nto.
Chaw Cia Ib Cheeb Tsam
 Khaws cov pwm nyob rau hauv qhov chaw qhuav thiab txias, tsis txhob muaj hnub ci ncaj qha lossis lub siab {}} huab cua ib puag ncig.
Kho thiab Kho Dua
 Yog tias cov pwm raug puas ntsoog, nws tuaj yeem kho nrog epoxy cov khoom ntim mus rau ntev kev pabcuam lub neej ntawm cov pwm.

Sib piv cov lus ntawm pes tsawg zaus cov pwm siv

Mould Hom	Kev tsim khoom lag luam	Tus naj npawb ntawm cov sijhawm siv	Muaj cov xwm txheej muaj feem xyuam
Txhuas Mould	5-15 hnub	Txog 500-1000 zaug	Haum rau me me batch ntau lawm los yog qauv qauv kev txhim kho, siv tsawg dua, tsim nyog rau kev tiv thaiv sai.
Saj zawg zog Hlau pwm	10-30 hnub	Txog 5000-10000 zaug	Haum rau me me thiab nruab nrab -}}} qhov me me batch ntau lawm, siv sijhawm ntau, tsim nyog ntau lawm nrog cov kev xav tau nruab nrab.
Silicone Mould	2-7 hnub	Txog 10-50 lub sij hawm	Haum rau kev tiv thaiv ceev, kev tsim me me lossis artwork, thiab lwm yam. Lim siv yooj yim, haum rau seem nrog rau cov duab nrog cov duab nyuaj.
3D Luam Ntawv Tuaj Pwm	1-7days	Txog 10-100 zaug	Haum rau tsawg ntim ntau lawm, prootyping lossis complex qhov chaw, tab sis tsis ruaj khov thiab tsis haum rau kev siv ntev ntev.
Epoxy Resin Pwm	5-10days	Txog 100-500 Times	Muaj feem xyuam rau me thiab nruab nrab - qhov loj me ntau ntau ntau lawm, kev siv ntau dua, tab sis tseem tsawg dua ruaj khov dua li cov pwm pwm.



Yuav Ua Li Cas Xaiv Qhov Zoo Tshaj Kev Txhaj Tshuaj Pwm?

Qauv kom muaj nuj nqis

Xaiv 3D luam ntawv pwm lossis silicone tuaj pwm rau me me; Xaiv aluminium pwm los yog mos hlau pwm rau nruab nrab kom muaj nuj nqis.

Cov khoom lag luam

Aluminium los yog mos steel pwm rau cov kev ntsuas siab thiab nto tiav.

Lub sijhawm raug nqi

Thaum lub sij hawm yog nruj, xaiv 3D luam ntawv pwm lossis pob zeb silicone.

Kev Siv Nyiaj Txiag

Thaum cov nyiaj txiag tsawg, xaiv Epoxy cob lossis silicone pwm.

Nws yuav tsum tau xaiv tias kev xaiv ntawm tag nrho cov kev txhaj tshuaj molding cov qauv tsim nyog yuav tsum tau xaiv cov qauv ua lag luam uas haum tshaj plaws
